Capacities

- 16,000kg @ 1200mm LC to full lift height

Mast

- 2 Stage Non Free Lift Mast

- 3974mm Maximum Lift Height

- 3680mm Overall Lowered Height

- 15* Forward Tilt / 10* Back Tilt

Forks

- 2440mm Length Pin Type Tines

- Tine Section: 2440mm Long x 90mm Thick x 250mm Wide

Carriage & Attachment

- Hydraulic Fork-Positioning

- Side-Shift Carriage

- 5 Function (3 Auxiliary) Hydraulic Valve

- Hydraulics controlled by 3 Levers and 2 Rocker Switches - Not For Clamping Attachments

Engine

- Cummins QSB 6.7L Tier 3 / Stage III Diesel Engine

- Rated Power 156hp / 116kw @ 2300rpm

Powertrain

- Drive Axle Kessler 18T

- Steer Axle 18T

- ZF WG161 3-Speed Transmission with 3 Speeds Forward and 3 Speeds Reverse

Wheels

- Tires 12.00x20/20PR Pneumatics

- Wheel Nut Protection Ring on Steer Axle

Operator Compartment

- Air Conditioning

- Enclosed Cabin

- Full Instrumentation Panel with Touch Screen 7inch Display

- Deluxe Air Ride Full Suspension Cloth Seat with High Backrest

Included Extras

- Lockable Battery Isolator

- Weight Gauge

- LED Work Lamps

- Amber Strobe Light - Ignition Activated

- Heavy Duty Air Intake

- High Mount Exhaust - Tier 3/Stage III

- Automatic Engine Shutdown with Timer

- Audible White Noise Reverse Alarm (SPED)

Built

- European assembly

Build Date: 10/2024

Unladen Weight: 23330kg

Rates are subject to rental term period, and application type - Please enquire for a quote.
